AI GPU Computer features 14th Generation Intel® Core™ processors with discrete NVIDIA and Intel GPU options for Edge AI Solution
Intel® Core™ i9 processor 14900T
Intel® Core™ i7 processor 14700T
Intel® Core™ i5 processor 14500T
Intel® Core™ i3 processor 14100T
R680E
2 x SO-DIMM Support DDR5-4800 up to 64GB
(ECC Support with ECC DRAM)
System power on/off 1 ~ 255 min setting by BIOS
2.0
Processor Built-in GPU – Intel® UHD 700 Series Graphics
Optional Discrete GPU
・NVIDIA RTX™ Embedded 2000 Ada / 3500 Ada / 5000 Ada
・Intel Arc A370E
Without Discrete GPU :
2 x HDMI®(Maximum Resolution : 4096 x 2160 @ 60Hz)
With Discrete GPU :
Additional 2 x HDMI (Maximum Resolution : 4096 x 2160 @ 60Hz)
Without Discrete GPU :
2 x DP 1.4 (Maximum Resolution : 7680 x 4320 @ 60Hz)
With Discrete GPU :
Additional 2 x DP 1.4 (Maximum Resolution : 7680 x 4320 @ 60Hz)
1
1
1
2 x I226-IT 2.5GbE RJ45 and 8 x I210-AT GbE RJ45
(Optional PoE with Total 120W Power Budget and M12 X-coded Connectors)
4 x RS-232/422/485
8 x USB 3.2 Gen 2×1 10Gbps
8 x DI (9~60VDC), 4 x DO (5V, 100mA)
2 x ADC (9~60VDC)
2 x M.2 2280 Key M for PCIe 4.0 x4 NVMe SSD
1 x M.2 2280 Key M for PCIe 4.0 x4 NVMe or SATA SSD (Auto Dectection)
2 x 2.5” Drive Bay for SATA Type SSD
* RAID 0/1/5 support via Intel® VMD.
2 x Mini-PCIe
2 x M.2 3042/52 Key B for WWAN (USB3.0) with Dual SIM Support
1 x M.2 2230 Key E for WiFi
DC 9-60V
OCP, OVP, Surge and Reversed Polarity Protection
Ignition Detection, and Power off Delay Time Setting by Software
Optional Internal Battery Kit for 10 Mins Operating Time (Charging Temp. 0~45°C, Discharging Temp. -10~60°C)
* UPS backup time varies depending on actual overall system power consumption and battery is required to be charged before using.
290(L) x 250(W) x 98(H) mm
8.5kg
Aluminum Alloy
Wall-mount
10% RH – 90% RH (non-condensing)
-40°C ~ 70°C w/0.6 m/s airflow (for barebone system)
*The operating temp. varies by accessories installed. Patent No. : M565941 – Thermal Cooling
-40°C ~ 80°C
MIL-STD-810G, Method 514.6, Procedure I, Cat.4 (Operating)
IEC60068-2-64, random, 2.5G@5~500Hz, 1hr/axis
MIL-STD-810G, Method 516.6, Procedure I,
Trucks and semi-trailers=15G (11ms) with SSD (Operating)
Certified with CE, FCC and E-Mark
Compliant with EN 50155, EN 45545-2 R25 Standards
Windows 10 IoT Enterprise LTSC
Windows 11 IoT Enterprise LTSC
Ubuntu Desktop 22.04
ABOX-5220xy-zz (x= P= w/PoE, x= Empty= w/o PoE, y=G=w/ Discrete GPU, zz=i9=i9-14900T, zz=i7=i7-14700T, zz=i5=i5-14500T, zz=i3=i3-14100T
Intel® 14th Generation Core™ Processor with Optional NVIDIA RTX™ Embedded GPU for AI Acceleration On-Board Computer
Made in Taiwan
