NVIDIA® Jetson Orin™ Lightweight AI Drone Computer
Innovation shouldn’t be limited by hardware. The IBOX-604-G2 acts as the resilient “brain” for your smartest projects—from high-precision AI visual inspection in modern factories to real-time consumer analytics in intelligent retail. It seamlessly turns complex data into actionable insights, giving you the confidence to push boundaries and redefine what’s possible at the edge.
In the world of UAVs and autonomous robotics, every gram and millimeter counts. The IBOX-604-G2 delivers massive AI processing power in an ultra-lightweight, slim profile, making it the ultimate edge controller for industrial drones. Whether it’s for real-time aerial mapping, infrastructure inspection, or coordinating complex drone swarms, its robust design ensures that high-altitude intelligence is no longer a challenge, but a standard.
From the freezing cold of remote outdoor surveillance to the constant vibration of smart public transit and fleet management, the IBOX-604-G2 is built to endure alongside you. We’ve engineered every detail to provide unwavering stability against extreme temperatures and power fluctuations. It’s more than just a computer; it’s a promise of continuity for critical mission-based applications in an unpredictable world.
Platform Security Controller (PSC), Security Engine (SE)
Auto reset for unresponsive system
Built-in 3-axis accelerometer
• 1 x M.2 3042/3052 Key B for WWAN w/ dual SIM support
• 1 x M.2 2230 Key E for Wi-Fi/BT (For IBOX-604-G2W only)
1 x M.2 2242 Key M for NVMe SSD
DC 10-60V (nominal power input DC 11V/22V/58V) via 3-pin terminal block
OCP, OVP, surge protection, reversed polarity protection
Ignition detection, Smart Power Management
Built-in RTC coin cell battery
1 x HDMI® Type-A output
1 x HD audio output via HDMI®
• 1 x 2.5GbE (Intel® I226-IT) via RJ-45
• 1 x GbE (NVIDIA SoM) via RJ-45
2 x GMSL-2 via FAKRA
1 x CAN FD
2 x USB 3.2
1 x DI, 1 x DO, I2C (optional)
1 x UART w/ 3.3VDC (connector shared with CAN FD)
1 × RS-232/422/485
1 x USB type-C for system recovery (device only)
NVIDIA® JetPack 6.2 or above
(Jetson Linux and NVIDIA® development tools included)
CE, FCC Class A, UKCA
-25°C ~ 50°C (-13°F ~ 122°F) with 0.6 m/s airflow
*Operating temperature varies by accessories installed.
-40°C ~ 80°C (-40°F ~ 176°F)
10% RH ~ 90% RH (non-condensing)
• MIL-STD-810H, Method 514.8, Procedure I, Cat.4 (Operating)
• IEC60068-2-64, random, 2.5G@5~500Hz, 1hr/axis
MIL-STD-810H, Method 516.8, Procedure I,
Trucks and semi-trailers=15G (11ms) with SSD (Operating)
Aluminum Alloy
3 x SMA connector mounting hole
Wall mounting
< 333 g (Excluding enclosure)
*Included enclosure w/o M.2 2230 slot (1 x SoM, 2 x DB-9 cable)
120 x 115 x 32 mm (4.73 x 4.53 x 1.26 in.)
NVIDIA® Jetson Orin™ NX SoM w/ 2 x GMSL / 1 x CAN FD / 1 x UART Lightweight AI Drone Computer
Made in Taiwan
M.2 2242 Key M NVMe SSD -40°C ~ 85°C
M.2 2230 Key A-E Wi-Fi module, -40°C ~ 85°C
M.2 3042/3052 Key B WWAN module, -40°C ~ 85°C
M.2 2242 Key B GNSS module, -40°C ~ 85°C
AC/DC 100-240V/12V 60W C14 DC plug power adapter
