Intel Atom® x7000RE DIN-rail PoE Fanless Rugged Edge Computer
• Industrial Grade Amston Lake Processor and Ethernet Controller
• Intel® Twin Lake Processor SKU Available
• 1 x 2.5GbE, 4 x PoE Ports for IoT Devices Connectivity
• 1 x Built-in CAN FD for Vehicle Device Communication
• Dual NVMe SSD Support for NVR Applications
• Built-in Watchdog and Smart Power Management for System Health Monitoring
• Supports DIN-rail and Wall-mount Installation
Intel Atom® x7835RE Octa-core Processor up to 3.6 GHz
Intel Atom® x7433RE Quad-core Processor up to 3.4 GHz
Intel® Twin Lake N355 Core™ 3 Octa-core Processor up to 3.9 GHz*
Intel® Twin Lake N150 Quad-core Processor up to 3.2 GHz
Intel® UHD Graphics
1 x SO-DIMM DDR5 up to 16 GB
Auto reset for unresponsive system
1 x TPM 2.0
1 x HDMI® with support for 4K@60Hz as specified in HDMI 2.0b
1 x Line-out, 1 x Mic-in (Optional)
• 1 x 2.5GbE from I226-IT via RJ-45 or M12 X-code for PoE model
• 4 x GbE* from Marvell Ethernet Switch w/ PoE (PSE Class 3: 15W) via RJ-45 or M12 X-code
* Share with 1GbE bandwidth; Power budget: 60W
**Non-PoE model: 2 x 2.5GbE
***M12 X-code cable is not included in the package
1 x CAN 2.0
2 x USB 3.2, 2 x USB 2.0
2 × RS-232/422/485 ports, expandable with 4 optional COM ports
8 x DI (9-60VDC), 4 x DO (12VDC/100mA)
• 1 x M.2 3042/3052 Key B for WWAN with dual Nano SIM support
• 1 x M.2 2230 Key E for Wi-Fi/BT
• 1 x M.2 2280 Key M for NVMe SSD
• 1 x M.2 2280 Key M for NVMe/SATA SSD
x7000RE Processor: -40°C ~ 70°C (-40°F ~ 158°F) with 0.6 m/s airflow
N-series Processor: -30°C ~70°C (-22°F~158°F) with 0.6m/s airflow
*The x7000RE processor for non-PoE models can operate up to 75°C (167°F), the processor performance may be limited.
** Operating temp. varies by the accessories installed.
-40 ~ 80°C (-40°F ~ 176°F)
10% RH – 90% RH (non-condensing)
• IEC 60068-2-64, random, 2.5G@5~500Hz, 1hr/axis
• MIL-STD-810H, Method 514.8, Procedure I, Category 4
MIL-STD-810H, Method 516.8, Procedure I, trucks and semi-trailers=15G (11ms)
DC 9 – 60V Input
OCP, OVP, surge protection, reversed polarity protection
Ignition detection, Smart Power Management
Backup battery for system power backup
* Non-PoE model only
Windows 11 IoT Enterprise LTSC, Ubuntu 24.04 LTS
Aluminum Alloy with Fanless Design
6 x SMA connector panel mount hole
DIN rail, Wall-mount
• RJ-45 model: 150 x 150 x 65 mm (5.91 x 5.91 x 2.56 in.)
• M12 PoE model: 150 x 150 x 87 mm (5.91 x 5.91 x 3.43 in.)
CE, FCC Class A, UKCA, E-Mark, EN 62368-1 EN 50155, EN 45545-2 (R25)
| VBOX-3132P |
VBOX-3132P-yyyy-zzzzz (yyyy=M12X; zzzzz=x7835=Intel Atom® x7835RE, zzzzz=x7433=Intel Atom® x7433RE) |
| VBOX-3132-D25-M12X | VBOX-3132-D25-M12X-zzzzz (zzzzz=x7835=Intel Atom® x7835RE, zzzzz=N150 =Intel® Processor N150) |
| VBOX-3132-D25 | VBOX-3132-D25-zzzz (zzzz=N355=Intel® Core™ 3 Processor N355, zzzz=N150=Intel® Processor N150) |
| VBOX-3132P | Intel Atom® x7000RE 4-Port PoE M12/RJ-45 DIN rail Rugged Edge Computer |
| VBOX-3132-D25-M12X | Intel Atom® x7000RE/Twin Lake Dual 2.5GbE M12 DIN rail Rugged Edge Computer (BBU for Option) |
| VBOX-3132-D25 | Intel® Twin Lake Processor Dual 2.5GbE RJ-45 Fanless Edge Computer (BBU for Option) |
Made in Taiwan
DDR5 SO-DIMM 16GB
M.2 2280 NVMe SSD 256GB~2TB
M.2 2230 Wi-Fi Module
M.2 3042/3052 WWAN Modem
M.2 3042/3052 WWAN Modem
M.2 2242 GNSS Module
BAT-2300v2 (Operating Temp.: -20°C~60°C (-4°F~140°F) (Only for non PoE model)
Non-PoE model: DC 12V, 60W
PoE model: DC 12V, 120W/160W
M12 X-code to RJ-45 (1M)
Taipei, Taiwan, December 18, 2025 – SINTRONES Technology Corp. (TWSE 6680), a global leader in edge AI computing, highlights its VBOX-3132 series, a compact in-vehicle computer engineered for seamless installation in space-constrained environments such as industrial cabinets. Engineered for reliability in harsh conditions, this edge computing solution features hardware expandability, flexible connectivity, and a modular, customizable design, making it the ideal choice for diverse industrial and transportation applications. Seamless Integration into Industrial Environments Designed for easy installation, this space-saving and portable computer supports both wall and DIN-rail mounting while consolidating most I/O ports on one side to maximize space efficiency and streamline cable management. With its versatile mounting options and compact design, the VBOX-3132 series fits effortlessly into constrained spaces, especially suited for deployment in NEMA enclosures or transport vehicles. Scalability and Connectivity for Smart Surveillance and Transportation Featuring Intel Atom® x7000RE Amston Lake CPU with extended temperatures that can operate reliably in industrial environments, SODIMM DDR5 memory, and two M.2 2280 slots for two NVMe SSDs to fulfill storage expansion needs, the VBOX-3132 series is scalable to handle increasing data loads without performance degradation. In terms of multi-connectivity, the industrial-grade computer provides one 2.5GbE uplink port for efficient data transfer to reduce network congestion, plus four PoE Ethernet ports for IP cameras, LiDAR, or other peripherals connections to increase situational awareness. Additionally, with the built-in CAN 2.0 port, which plays a vital role in seamless integration and communication within vehicles, the VBOX-3132 series is tailored for intelligent transportation and surveillance applications that require real-time video recording and playback, object detection and tracking, data analytics and decision-making. Versatile Design to Fulfill Diverse Needs The VBOX-3132 series offers...
Read more
