VBOX-3611-4L

Rugged Industrial Computer for Fleet Management

Intel Gen 6 Core i7-6600U CPU with 4 x GbE LAN On-Board Computer

Product Status: Available
Inquiry Datasheet
CE E13 EN 45545-2 R25 EN 50155

Features

  • Intel Core i7-6600U
  • Wireless support LTE w/ Dual SIM Cards, WLAN, GPS Dead Reckoning, WiFi, BT(Optional)
  • 9V~48V DC Power Input
  • Smarter Vehicle Power Ignition for Variety Vehicle
  • Dual Hot Swappable SATA Storage, RAID 0, 1, 5
  • 1 x CAN Bus 2.0B (Optional)
  • E13 and EN50155 certified

Introduction

The VBOX-3611-4L is powered by Intel Gen six Core i7-6600U CPU with four GbE LAN In-Vehicle Comptuer. It is designed for a wide range of DC power inputs 9V~48V DC which are isolated for power, serial and I/O port. It features an optional CAN Bus 2.0B port and wireless communication technology, offers wireless support LTE with SIM card, WLAN, GPS Dead Reckoning, and BT (Optional). It is E13 and EN50155 certified. VBOX-3611-4L provides four GbE, including one with iAMT. It features smart vehicle power ignition, power management for a variety of vehicles, and it can be adapted to the needs of any vehicle management systems, tracking the trains’, cars’, or trucks’ internal hardware and software states, usage and movement.

SYSTEM

Processor

Intel Gen 6 Core i7-6600U 2.6GHz up to 3.4GHz
Intel Gen 6 Core i5-6300U 2.4GHz up to 3.0GHz
Intel Gen 6 Core i3-6100U 2.3GHz
Intel Gen 6 Dual Core 3955U 2.0GHz

Chipset

Intel 6th Generation Core SoC Processor

Memory

2 x DDR4 2133 MHz SO-DIMM up to 32GB

Watchdog

Watchdog Timer Support, Offer 1 – 255 Step

TPM

2.0

GRAPHICS

Graphics Engine

Intel UHD Graphics 520 (for i7, i5, and i3)
Intel UHD Graphics 510 (for Celeron)

HDMI

N/A

DisplayPort

1

DVI

1

VGA

1

Resolution

Max Resolution (HDMI 1.4) : 4096 x 2304@24Hz
Max Resolution (DP) : 4096 x 2304@60Hz

AUDIO

Audio Codec

Realtek ALC662 HD Codec Onboard

Line-out

1

Mic-in

N/A

Line-in

1

ETHERNET

LAN Chipset

Intel I210-AT Gb/s Ethernet Controllers Onboard
Support PXE and WOL

LAN

4 x RJ45 Ports (opt. M12 connector) for GbE (1 port with iAMT)

PoE

N/A

I/O

Serial Port

4 x RS-232 (2 with RS-422/485 (Auto Direction Control))

USB

4 x USB 3.0 Ports

DIO

4 In and 4 Out

AIO

N/A

SIM Socket

2 x SIM Card sockets supported onboard with pin eject

Antenna

N/A

STORAGE

SSD/HDD

2 x 2.5″ Drive Bay for SATA Type
1 x SATA DOM

mPCIe

N/A

mSATA

N/A

M.2

1 x M.2 M key 2280 slot supports M.2 SATA SSD

RAID

0, 1, 5

EXPASION

Mini PCI Express

2 x Full Mini-PCIe (full function)

M.2

1 x M.2 2230 A-E Key, 2 x M.2 3042/52 B Key (USB 3.0 only)

POWER

Power Input

9V -48V DC Power Input

Power Protection

Automatics Recovery Short Circuit Protection

Smart Ignition

Vehicle Power Ignition for Variety Vehicle

Power-off Delay Control

Power off Delay Time Setting by Software and BIOS

Backup Battery Solution

Patented Battery Kit

MECHANICAL

Dimension

250 x 150 x 55 mm

Weight

2160g (bare-bone)

Construction

Aluminum Alloy

Mounting

Supports Both of Wall-mount/VESA-mount

ENVIRONMENT

Relative Humidity

10% RH – 90% RH (non-condensing)

Operating Temp.

-40 ~ 70°C

Storage Temp.

-40 ~ 85°C

Vibration & Shock

Vibration (with SSD):
IEC60068-2-64, random, 2.5G@5~500Hz, 1hr/axis
MIL-STD-810G, Method 514.6, Procedure I, Cat.4, Operating

Shock Operating:
MIL-STD-810G, Method 516.6, Procedure I,
Trucks and semi-trailers=15G (11ms) with SSD

IP Rating

N/A

CERTIFICATION

Certification

CE, FCC Class A, E13, EN50155, EN45545-2 (R25)
(The input Negative connects with chassis Ground)

Safety

Patent

M447854, M448011

ODERING INFORMATION

Model. No.

VBOX-3611-4L-i7

Description

Intel Gen 6 Core i7-6600U CPU with 4 x GbE LAN On-Board Computer

State of Origin

Made in Taiwan
