Standards, Types, and Applications of PoE Security Camera Systems


Power over Ethernet (PoE) technology is essential in networking and online security, providing a convenient and efficient solution for powering various devices. In this article, we will examine the basics of PoE, explore the benefits, discuss different types of PoE, and look at the applications of NVR PoE security in creating a robust PoE security system.

Image of a high-tech security camera integrated with PoE technology.

What Is Power over Ethernet (PoE) in Networking?

Introducing PoE Security System

Power over Ethernet (PoE) technology allows network cables to carry electrical power. For example, a digital security camera typically requires two connections to be made when it is installed. However, with PoE, only one network connection must be made as it will receive electrical power from the same cable.

There are two main types of PSE configurations: ENDSPAN and MIDSPAN. Put simply, ENDSPAM refers to switches with built-in PoE capabilities, and MIDSPAN refers to injectors between the controller and the PD.

With PoE, devices such as IP cameras, wireless access points, and VoIP landline phones can receive power and network connectivity from a single source, eliminating the need for separate power cables and adapters. PoE security system refers to a network setup incorporating Power over Ethernet technology, enabling electrical power and data transmission over a single Ethernet cable.

How Does PoE Security Systems Work?

PoE operates using two main components: Powered Devices (PD) and Power Sourcing Equipment (PSE). PoE technology utilizes network cables, such as Cat 5e and Cat 6. PoE takes advantage of the fact that electrical currents require a loop with two conductors to deliver power over the cable. Each pair of wires within the cable is treated as a single conductor, allowing PoE to utilize either two data or two spare pairs to carry electrical current. Power is injected onto the cable at a relatively high voltage (typically between 44-48 colts) for efficient power transfer while maintaining safe electrical levels.

Distance Limitations with PoE Security Systems

When considering a PoE security system, it is vital to consider the distance limitations. The maximum distance that power and data can be transmitted over Ethernet cables in a PoE security system depends on various factors. These factors include the cable quality and power requirements of the connected devices. As a general guideline, the maximum distance for functional PoE is 100 meters (328 feet). Beyond this distance, power loss and data degradation may occur, potentially affecting device performance.

Benefits of Using PoE Security Systems

Image of a security manager viewing live PoE camera footage.

  1. Flexibility: A PoE security system provides the flexibility to deploy devices in locations without easy access to power outlets. This makes it ideal for installations in remote areas or with limited power availability.
  2. Easy Installation: The PoE installation process is simplified, as there is no need for separate power cables and outlets. This reduces the overall complexity of installation, making it a time-saving solution.
  3. Cost Reduction: PoE security systems eliminate the need for additional electrical infrastructure, resulting in cost savings. It reduces installation fees, purchasing power adapters, and managing multiple power sources.
  4. Central Remote Control: A PoE security system allows centralized power management and control. Administrators can remotely monitor and manage PoE-enabled devices through a network switch.
  5. Power Protection: PoE adheres to IEEE802.3af/IEEE802.3at standards, providing protection mechanisms such as short circuit protection, over-low voltage protection, and over-current protection. This ensures the safety and longevity of connected devices.

Introducing PoE Types and Power Levels

A PoE security system encompasses different types of PoE with varying power levels. The three main PoE types commonly used are PoE, PoE+, and PoE++. These types determine the power output and the devices supported within the PoE security system. The table below demonstrates the capabilities of each PoE, including the recommended maximum power per port and supported devices:

PoE Type

IEEE Standards

Power to PD

Max. Power per Port

Supported Devices


IEEE 802.3af



VoIP phones, wireless access points


IEEE 802.3at



PTZ cameras, video phones


IEEE 802.3nt (Type 1 or Type 2

51W or 71.3W

60W or 100W

Video conferencing equipment, multi-radio wireless access points, laptops, flat screens


What Are NVR PoE Security Cameras?

NVR PoE security system cameras are commonly found in commercial security camera systems. NVR stands for Network Video Recorder, a device that records and manages video footage from IP cameras. PoE security cameras have built-in PoE functionality, allowing them to receive power and data directly from the Ethernet cable connected to the NVR for local storage.

Difference between DVR and NVR Cameras

Understanding the distinction between DVR (Digital Video Recorder) and NVR cameras. DVR cameras are analog-based and require separate power and video cables. These cameras are commonly used for small applications which do not require long-distance data transfer or remote viewing.

On the other hand, NVR cameras are IP-based, utilizing network cables for both power and video transmission. NVR cameras are called PoE security camera systems, a more flexible and efficient technology than CVR. These cameras can process video data before sending it to the recorder and are commonly used in applications that require more precise and complex functionality.

How Does a PoE Security Camera Work?

A PoE security system camera connects to the NVR via an Ethernet cable, receiving power and data from the same cable, eliminating the need for additional power sources. This setup offers flexibility in camera placement, as the cameras can be installed in various locations without the constraint of proximity to power outlets.

Application of NVR Security Cameras

NVR PoE security system cameras find applications in a wide range of settings, including:

  1. Security cameras on campus and in offices: NVR PoE cameras provide effective surveillance solutions for educational institutions, office buildings, and corporate campuses. They enable real-time monitoring, recording, and playback of video footage, ensuring the safety and security of the premises.
  2. Intelligent transportation, such as buses or fleet passenger surveillance: PoE cameras can be installed in buses and fleet vehicles to enhance passenger safety and security. They can record video footage of the vehicle’s interior, helping to deter vandalism, monitor passenger behavior, and investigate incidents.
  3. Smart agriculture and plant surveillance: NVR PoE cameras can be implemented in agriculture systems to monitor crops, greenhouses, and agricultural facilities. They enable farmers to remotely monitor plant health, detect pests, and ensure optimal growing conditions.
  4. ANPR/LPR and AIoT Applications: Automatic Number Plate Recognition (ANPR) and License Plate Recognition (LPR) systems utilize NVR PoE cameras to capture and analyze license plate information. These systems are used in parking lots, toll booths, and traffic management to automate time-consuming processes.


How to Select the Right PoE Security Camera System?

Several factors should be considered when choosing a PoE security system camera system. It is essential to evaluate the quality and reliability of the components in the intelligent PoE security camera system. This includes both the NVR camera and the server.

  • NVR camera specifications: Consider the resolution and video quality offered by the camera. Higher resolutions, such as 1080p or 4K, will provide more transparent and precise images suitable for applications such as ANPR and LPR. Additionally, assess the camera’s night visibility capabilities to ensure effective surveillance in low-light conditions.
  • Server: Evaluate the PoE capabilities of the server, as it needs to provide sufficient power to all connected cameras. Ensure the server has adequate computing power for efficient video data processing, especially if you implement advanced analytics or AI-driven applications.

PoE technology offers businesses a professional, informative, and efficient solution for powering devices. Its flexibility, streamlined installation, cost reduction, and centralized control capabilities make it a preferred choice for enhancing security infrastructure worldwide. By leveraging PoE security systems, businesses can achieve reliable surveillance, optimize resources, and maximize operational effectiveness.

Visit our website to explore our comprehensive range of outdoor video surveillance solutions, including cutting-edge PoE security systems. Take a proactive step towards enhancing your security infrastructure today.
